400MHz 60w Anti drone Module RF Module For Drone

As one of the professional China 400MHz 60w Anti drone Module RF Module For Drone J products manufacturers and China signal jammer factory, Shenzhen Rongxin Communication Co., Ltd is strong strength and complete management.We have specializing in signal jamming especially for drones more than 10 years.

Send Inquiry

Product Description

400MHz 60w Anti drone Module RF Module For Drone Jammer

As one of the professional China anti drone products manufacturers and China signal jammer factory, Shenzhen Rongxin Communication Co., Ltd is strong strength and complete management.We have specializing in signal jamming especially for drones more than 10 years.

RX 400MHz 60w Anti drone Module RF Module For Drone Jammer Introduction

This RX 400MHz 60w anti drone module RF module for drone jammer is the latest design by Rongxin with 1-year warranty. RX 400MHz 60w anti drone module RF module for drone jammer has the advantages of high average output power ( 60 W output in stable operation), good in-band flatness, and small offset between upper and lower sidebands.

RX 400MHz 60w Anti drone Module RF Module For Drone Jammer Specification

RX 400MHz 60w Anti drone Module RF Module Specification
No.	Item	Data	Unit	Notes
1	Frequency	425-440	MHZ
2	Work Temperature	-10~+75	℃
3	Output Power	40	W
4	Work Voltage	DC24	V
5	Max Gain	46±1.5	dB
6	Flatness	±3	dB
7	Max Current	3.2	A
8	Output VSWR	≤1.5
9	Output Connector	SMA		customized
10	Power Amplifier Efficiency	41.6		when Max Output
11	Switch Control	high low level current	V	0V off /0.6 on
12	Standing Wave Protection	OK
13	Temperature Protection	75°	℃
14	Size	1375818	mm
15	Weight	0.25	Kg

RX 400MHz 60w Anti drone Module RF Module For Drone Jammer Precautions

Ø Power supply needs to have 28V /5A

Ø If the output power is greater than 5W and above, it is recommended to strengthen the heat dissipation treatment, such as adding a heat sink or adding a fan.

Ø When connecting, you must first screw on the antenna, then connect the front-end source device, and finally supply power
