2400-2500mhz 3dbi Omni Antennas

This high-gain omnidirectional antenna is designed for the 2.4GHz frequency band, providing stable and reliable signal transmission in the 2400-2500mhz 3dbi Omni Antennas. With its high gain of 3 dBi, it can significantly enhance signal strength and expand coverage, making it suitable for various wireless communication application scenarios. Rx as a professional module manufacturer, you can rest assured to buy module from our factory and we will offer you the best after-sale service and timely delivery.

Send Inquiry

Product Description

This high-gain omnidirectional antenna is made of high-quality materials and has good durability and anti-interference ability. It can work stably in various harsh environments to ensure long-term, reliable performance. It can be applied to a variety of wireless devices, such as wireless routers, wireless access points, Wi-Fi extenders, etc. It can be perfectly compatible with devices of different brands and models, providing you with more choices and flexibility.

High Gain 2400-2500MHz 3dbi omni antennas specification

Electrical Specifications
Frequency Range	2400-2500 MHz
Gain(dBi)	3±0.5dBi
VSWR	≤1.5
Polarization	vertical
Horizontal Beamwidth(0º) Vertical Beamwidth(0º)	360º 55±5º
ovality(dB)	≤±2dB
Input Impedance（Ω）	50Ω
Maximum input power(W)	50W
Input connector type	N-K
Lightning Protection	DC Ground
Mechanical Specifications
Dimensionsmm(Height/Width/Depth)	ɸ32*149mm
Antenna weight(kg)	0.136KG
Rated Wind Velocity（m/s)	60m/s
Operational Humidity(％)	10- 95
Radome Color	black
Radome material	glass fiber reinforced plastics
Operating temperature(ºC)	-40～55 º
Installation Method	Machine installation
