1.5GHz 100W Anti Drone Signal Jammer Module

Rongxin is a manufacturer and supplier of 1.5GHz 100W Anti Drone Signal Jammer Module in China that provides wholesale anti-drone signal jammers. We offer professional service and competitive pricing. If you are interested in jammer products, please contact us. We promise to provide quality products and dedicated service.

Send Inquiry

Product Description

China's Rongxin company offers high-quality anti-drone signal jamming modules. You can buy high-quality anti-drone signal jamming modules directly from Rongxin with a low price.It is a wireless information security module dedicated to 1560-1620MHz signals. This module has the advantages of high average output power, good in-band flatness, and small offset between upper and lower sidebands.

Regular type with signal source，if you want without signal source type also can offer（input signal 0-10dBm）

Rongxin 1.5GHz 100W Anti Drone Signal Jammer Module Specification

No.	Item	Data	Unit	Notes
1	Frequency	1560-1620	MHZ
2	Work Temperature	-20~+70	℃
3	Max Output Power	100	W
4	Input power	5	dBm	0-10dbm optional Regular type with VCO inside no need input
5	Work Voltage	24-28	V
6	Max Gain	50	dB
7	Max Current	10	A
8	Impedance	50Ω
9	Output Connector	N/F		Customized
10	Power Amplifier Efficiency	45		when Max Output
11	Switch Control	high low level current	V	24-28V OrCustomized
12	Power adjustable	Customize		Can make if you need
13	Standing Wave Protection	OK
14	Temperature Protection	75°	℃
15	Size	20210227	mm
16	Weight	0.91	Kg

Precautions for use

√ Power supply needs to carry more than24V 10A

√ If the output power is greater than 5W and above, it is recommended to strengthen the heat dissipation treatment, such as adding a heat sink or adding a fan.

√ When connecting, you must first screw on the antenna, then connect the front-end source device, and finally supply power
